Rahmen |
eONE-EIGHTY LITE; MAT Aluminum; 180 STR; 29” x 2,6” max. WHS; 148×12 AST; intube; |
Größe |
XSHORT,SHORT,MID,LONG,XLOONG |
Federung / Dämpfer |
Rock Shox Vivid Coil Ultimate; coil spring rates: XSHORT and SHORT: 300lbs – MID: 350 lbs – LONG: 400 lbs – XLONG: 450 lbs |
Gabel |
Rockshox Zeb Ultimate eMTB; Air; 180 STR; Tapered; 44mm fork offset; 29×2.6″ max WHS |
Vorderbremse |
Sram Maven Base; 4 piston |
Hinterbremse |
Sram Maven Base; 4 piston |
Bremsscheibe vorne |
Sram CenterLine; 220mm |
Bremsscheibe hinten |
Sram CenterLine; 200mm |
Kette |
Sram Eagle 70 Flattop Chain |
Kettenblatt |
Sram Eagle Transmission E-MTB for Bosch; 36 ATC |
Kurbel / Größe |
Sram S1000 Eagle E-MTB Crank, 160mm all sizes |
Schaltwerk (hinten) |
Sram Eagle 70 Transmission |
Freilauf |
Sram CS XS 1270 T-TYPE 10-52; 12 GER |
Pedal |
VP VP-532 |
Griff |
MERIDA EXPERT TR |
Lenker |
MERIDA EXPERT eTR; 780 WHB; |
Lenker-Vorbau |
MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount |
Vorbau / Größe |
40 mm all sizes |
Steuersatz |
Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
Kompressor (Steuersatzteil) |
Star Nut |
Spacer / Distanzring |
2*10mm, 1*2.5mm |
Vorderradnabe |
Novatec SL-ELITE D041SB-B15; 110×15 WHF; 32 SPH; 6 bolt |
Hinterradnabe |
Novatec SL-TEAM D462SB-S3S-B12-11S; 148×12 WHR; 32 SPH; 6 bolt |
Hinterachse |
MERIDA EXPERT TR; including removeable lever, 6/4mm allen key |
Reflektor |
DIN |
Felge |
Reynolds 309 Enduro Comp; 30 IWR; MAT aluminium; Tubeless ready (tubeless tape installed); front 29″; rear 27.5″ |
Felgenband |
Stans 30mm tubeless tape installed |
Sattel |
MERIDA COMP SL; V-mount; incl. MERIDA minitool |
Sattelklemme |
MERIDA EXPERT |
Sattelstütze |
MERIDA TEAM TR II; 34.9 DSP; 0 SSB; SHORT, MID, LONG and XLONG 30-230 SPT; XSHORT 30-200 SPT |
Schalthebel vorne |
Sram Dropper Lever MMX |
Schalthebel hinten |
Sram Eagle 70 Transmission Shifter |
Klemme vorne |
Bosch clamp and screw for the Display |
Speiche |
Black stainless ; black nipples |
Schlauch |
Front Lite-29×2.2-2.5, Rear Lite-27,5×2.2-2.5 |
Vorderreifen |
Maxxis Assegai; 29×2.5 „; fold; TR EXO+ 3C MaxxGrip |
Hinterreifen |
Maxxis Minion DHR II; 27.5×2.4 „; fold; 3C DD TR MaxxTerra |
Befestigungsteile / Kleinteile |
stainless |
Aufkleber / Dekor |
under coating |
Schutzteil 1 |
CSP-104 |
Karton |
A5 [ebike] fully |
Handbuch |
MERIDA eBike Manual |
Lackierung |
frame |
Verpackung |
0,95 |
Klingel |
Alloy |
Kettenführung / -spanner |
CH-MDE-MINI(2) |
Schutzblech |
RF-001 mini fender |
Vorderlicht |
Lezyne Hekto StVZO E350+ Reverse; reverse MERIDA Custom Mount |
Rücklicht |
USB REAR Light CG-214RG |
E-Schaltteil 1 |
OD25 PROTECTIVE SOUND REDUCING SLEEVE |
E-Schaltteil 2 |
ADA-002 |
E-Schaltteil 3 |
CR-039 charging port cover |
Antriebseinheit |
Bosch Performance Line CX |
Antriebsabdeckung |
CR-038 PC 黑色 bottom cover |
Akku |
Bosch PowerTube 800 ; 800Wh |
Akkuhalter |
Bosch Guide Rail PT800 Horizontal |
Ladegerät |
Bosch 4A Charger (220-240V) |
Akkuschloss |
Abus Key |
Geschwindigkeitssensor |
Bosch Speedsensor Cable Slim 815mm |
Schalter |
Bosch Mini Remote |
Display |
Bosch Purion 400 |
Elektrokabel |
Bosch Cable Battery 400mm (Taped) |
Akkudeckel |
MERIDA Custom Battery Cover w/ Fidlock |
Satelliten-Ladeanschluss |
Bosch Cable PowerTube Charging Socket 350mm |
Ladeadapter |
Bosch Charger Power Cable Europe |
Einschaltknopf |
Bosch System Controller |
Größe : | XS, S, M, L, XL |
---|
